9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
10.27
SPN FMI COMPONENT CONDITION DTC
516106
3
Valve Driver Front Left
(Dynamix only)
Short/Voltage too high
C102B
4
Short/Voltage too low
C102A
516107
3
Valve Driver Front Right
(Dynamix only)
Short/Voltage too high
C100E
4
Short/Voltage too low
C100D
516108
3
Valve Driver Rear Left
(Dynamix only)
Short/Voltage too high
C100C
4
Short/Voltage too low
C100B
516109
3
Valve Driver Rear Right
(Dynamix only)
Short/Voltage too high
C1009
4
Short/Voltage too low
C100A
516110
3
Shock Valve Supply Relay
Driver (Dynamix only)
Short/Voltage too high
C102D
4
Short/Voltage too low
C102C
516111 11
Absolute Shock Current Error
- Front Left (Dynamix only)
Above Maximum C104D
516112 11
Absolute Shock Current Error
- Front Right (Dynamix only)
Above Maximum C104E
516113 11
Absolute Shock Current Error
- Rear Left (Dynamix only)
Above Maximum C104F
516114 11
Absolute Shock Current Error
- Rear Right (Dynamix only)
Above Maximum C105F
516115
12
Acceleration Input
Invalid C0520
15 Valid but above normal C105B
17 Valid but below normal C105C
516116 9
Engine Speed Input
Time Out U1102
516117 9
Steering Angle Input
Time Out U1131
516118 9
Accelerator Pedal Position
Input
Time Out U1103
516119 2
SW Version / HW Version
Compatibility
Data Inconsistent C105E
516120 9
Vehicle Speed Input
Time Out U1101
516121 9
Transmission Requested
Range
Time Out U105D
516122
15
Steering Angle Adaptation
Offset (Dynamix only)
Above Maximum C1097
17 Below Minimum C1098
516123
2
Vehicle Speed Data
Invalid U102E
20
Plausibility fault
U1080
21 Slew Rate check U108B
516124 12 CPU
Bad Intelligent Device
C1008
516125 11 CAN1 Error U0029
516126
0
System Voltage
Way above MAX
C1096
1
Way below MIN
C1095
3
Short/Voltage too high
C1099
4
Short/Voltage too low
C109A
16 Above MAX C108F
18 Below MIN C108E
520572 2 Brake Switch Status Invalid U108C
520574 2
Accelerator Pedal Position
Data
Invalid U143D
524000 2
Engine Speed Data
Invalid U102F
DIAGNOSTIC
