9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
12.5
ELECTRICAL COMPONENT LOCATIONS (REAR)
q
Tail Light Harness
s
MAG Injector
2!
Stator 1
w
ETC Throttle Body
d
PTO Injector
2@
Stator 2
e
Boost Pressure Sensor
f
TMAP Sensor
2#
Water Pump
r
Oxygen Sensor
g
Coolant Temp Sensor
2$
Seat Belt Switch
t
Vehicle Speed Sensor
h
Ignition Coil
2%
Chassis Ground
y
Transmission Switch
j
Ignition Coil Ground
2^
Fuel Pump and Sender
u
Crank Position Sensor
k
BAP Sensor
2&
Battery (-)
i
Starter (+)
l
Waste Gate Control
2*
Battery (+)
o
Engine Ground
1(
ECU
2(
Shock Actuator
a
Detonation/Knock Sensor
2)
Starter Solenoid
