7.10
9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
7. Torque wheel hub nut to specification and install a
new cotter pin
t
. Tighten nut slightly if necessary to
align cotter pin holes.
TORQUE
Hub Castle Nut:
180 ft-lbs (244 Nm)
8. Install wheel and four wheel nuts. Torque wheel nuts
to specification.
TORQUE
Wheel Nuts:
120 ft-lbs (163 Nm)
9. Rotate wheel and check for smooth operation. Bend
both ends of cotter pin around end of spindle in
different directions.
FINAL DRIVE
