9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
10.29
SPN FMI COMPONENT CONDITION DTC
520280 31
Throttle Body Control - Limp
Home Position Check Failed
Condition exists P151E
520281 31
Throttle Body Control -
Mechanical Stop Adaptation
Failure
Condition exists P152A
520282 31
Throttle Body Control -
Repeated Adaptation Failed
Condition exists P152B
520283
2
Throttle Body Control
Data erratic, intermittent or incorrect
P152F
3
Voltage above normal
P152C
4
Voltage below normal
P152D
520284 31
Throttle Body Control -
Position Deviation Fault
Condition exists P152E
520285 2 Brake Switch
Data erratic, intermittent or incorrect
P153E
520286 31
ECU Monitoring Error
Condition exists P1540
520287 31
ECU Monitoring Error (Level
3)
Condition exists P1541
520288 31
ECU Monitoring of Injection
Cut off (Level 1)
Condition exists P1542
520289 31
ECU Monitoring of Injection
Cut off (Level 2)
Condition exists P1543
520305 31
Throttle Body Control -
Requested Throttle Angle
Not Plausible
Condition exists P1530
520306 31 ECU ADC Fault - No Load Condition exists P1531
520307 31
ECU ADC Fault - Voltage
Condition exists P1532
520308 31
Accelerator Sensor Sync
Fault
Condition exists P1533
520309 31 ECU Fault - ICO Condition exists P1534
520311 31
ECU Fault - Hardware
Disruption
Condition exists P1537
520331
3
Knock Sensor Positive Line
Voltage above normal
P1327
4
Voltage below normal
P1328
520332
3
Knock Sensor Negative Line
Voltage above normal
P132A
4
Voltage below normal
P132B
520341
3
Wastegate Solenoid Driver
Voltage above normal
P0243
4
Voltage below normal
P0246
5
Current below normal or open circuit
P0245
520342
15
Idle Fuel Correction
Valid but above normal - Too Rich P116C
17 Valid but below normal - Too Lean P116D
520344
15
Adaptive Fuel Correction
Valid but above normal - Too Rich P0170
17 Valid but below normal - Too Lean P1170
520496
3
Intercooler Pump Driver
Circuit
Voltage above normal
P107D
4
Voltage below normal
P107C
5
Current below normal or open circuit
P107E
524086
3
EPS SEPIC Voltage Error
Voltage above normal
C106D
4
Voltage below normal
C106E
DIAGNOSTIC
