9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
12.9
q
Vehicle Speed Display - Analog display of vehicle speed in MPH or km/h.
w
Information Display Area - Odometer / Trip Meter / Tachometer / Engine Temperature / Engine Hours /
Service Info / Clock - LCD display of the service hour interval, total vehicle miles or km., total engine hours, a trip
meter, engine RPM and engine temperature.
e
MPH / KM/H Display - MPH is displayed when the instrument cluster is in the Standard mode. KM/H is displayed
when the instrument cluster is in the Metric mode.
r
High Beam Indicator - LED icon illuminates whenever the headlight switch is in the high beam position.
t
Fuel Level Indicator - LCD bar graph indicating current fuel level.
y
Clock - Displays current time in either 12-hour or 24-hour formats.
u
Engine Temperature Indicator - Illuminates when the ECU determines the engine is overheating. The indicators
will initially flash to indicate the engine is overheating. The indicators will stay lit and not flash if a severe overheating
condition exists.
i
Service Interval Indicator - Preset at the factory and adjustable by the user, a flashing wrench symbol alerts the
operator that the preset service interval has been reached and maintenance should be performed. The wrench icon
will flash for 10 seconds upon start-up once it reaches 0.
o
Check Engine MIL - Illuminates when the ECU has detected a Diagnostic Trouble Code in the engine
management system.
a
AWD Indicator - Illuminates when the AWD / TURF switch is in the AWD position.
s
Neutral Gear Indicator - Illuminates when gear selector is in the neutral (N) position.
d
Gear Position Indicator - Displays gear selector position.
H = High
L = Low
N = Neutral
R = Reverse
P = Park
– = Gear Signal Error (shifter stuck between gears)
f
Power Steering System MIL - Illuminates when a fault has occurred with the power steering system. This
indicator illuminates when the key is turned to the ON position and goes off when the engine is started.
g
Turn Signal / Hazard Lamp Indicator - Illuminates whenever the LH, RH or hazard lamps are activated (INT’L
Models Only).
h
Helmet / Seat Belt Indicator - Illuminates for several seconds when the key is turned to the ON position. The
lamp is a reminder to the operator to ensure all riders are wearing helmets and seat belts before operating the
vehicle.
j
ADC Indicator - Illuminates when Active Descent Control (ADC) is selected.
k
Performance Limited Indicator - Illuminates when engine performance is electronically limited.
l
Low Fuel Indicator - Illuminates when fuel level reaches lowest bar on fuel level indicator.
1(
Engine Speed Display - Analog display of engine speed in thousands of revolutions per minute.
2)
Parking Brake Indicator - Illuminates when parking brake is engaged (INT’L Models Only).
2!
Low Battery Indicator - Illuminates when battery voltage is low, charging system may be overloaded.
