Polaris RZR XP User Manual

12.38
9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
CIRCUIT PIN FUNCTION
16 Power In
21 Power Out
22 Coil Low
EPS 30A Fuse
17 Power In
23 Power Out
Shocks 7.5A Fuse (Turbo S Models)
18 Power In
24 Power Out
Lights Relay
25
Coil High
26 Power In
31 Power Out
32 Coil Low
Chassis 7.5A Fuse
27
Power In
33 Power Out
Socket 10A Fuse
28 Power In
34 Power Out
Shocks Relay
29
Coil High
30 Power In
35 Power Out
36 Coil Low
Lights 7.5A Fuse
37 Power In
43 Power Out
Instr Unsw 7.5A Fuse
38 Power In
44 Power Out
Chassis Relay
39
Coil High
40 Power In
45 Power Out
46 Coil Low
EFI 10A Fuse
41 Power In
47 Power Out
SCM 7.5A Fuse
42 Power In
48 Power Out
Pump Relay
49
Coil High
50 Power In
55
Power Out
56 Coil Low
Spare 7.5A Fuse
51
–
57
–
Spare 10A Fuse
52
–
58
–
SCM Relay
53
Coil High
54 Power In
59 Power Out
60 Coil Low
Water 7.5A Fuse
61 Power In
67 Power Out
Fuel 7.5A Fuse (10A for EVAP only)
62 Power In
68 Power Out
ELECTRICAL
