12
9929419 R02 - 2018-2019 RZR XP / XP 4 Turbo S Service Manual
© Copyright Polaris Industries Inc.
12.49
4. Click on the box next to the breakout diagram you
want to see. Deselect any other diagram that may be
selected.
5. Click on the Wiring Diagram (black & white) box to get
a shadow of the full diagram behind the break-out
diagram.
ELECTRICAL
