Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
1046User Manual 1178.8520.02 ─ 01
Suffix:
<n>
.
Window
<li> Limit line
Parameters:
<InterpolMode> LINear | LOGarithmic
*RST: LIN
Example:
CALC:LIM:CONT:SPAC LIN
Manual operation: See " X-Axis " on page 479
CALCulate<n>:LIMit<li>:LOWer[:DATA] <LimitLinePoints>
This command defines the vertical definition points of a lower limit line.
Suffix:
<n>
.
irrelevant
<li> Limit line
Parameters:
<LimitLinePoints> Variable number of level values.
Note that the number of vertical values has to be the same as
the number of horizontal values set with CALCulate<n>:
LIMit<li>:CONTrol[:DATA]. If not, the R&S FSV/A either
adds missing values or ignores surplus values.
The unit depends on CALCulate<n>:LIMit<li>:UNIT
on page 1049.
*RST: Limit line state is OFF
Default unit: DBM
Manual operation: See " Data Points " on page 479
CALCulate<n>:LIMit<li>:LOWer:MARGin <Margin>
This command defines an area around a lower limit line where limit check violations
are still tolerated.
Suffix:
<n>
.
irrelevant
<li> Limit line
Parameters:
<Margin> numeric value
*RST: 0
Default unit: dB
Manual operation: See " Margin " on page 479
Analyzing Measurements (Basics)
