10.4.3 20-pin conversion adapter for the PG-FP6
When the CoreSight 20-pin connector is used on the target system, use the 20-pin conversion adapter for
the PG-FP6. When the 10-pin connector is used on the target system, use the 20-pin to 10-pin conversion
cable to match it.
Remark: For the product information, refer to section 1.4, Optional Products.
Table 10.4 Pin Configuration of the Target Connector (20-Pin Type)
Signal Name
(PG-FP6)
15-Pin D-Sub Male
Connector
CoreSight 20-pin
Female Connector
CoreSight 10-pin
Female Connector
V
CC
8,9
1
1
FLMD1 6 2 2
GND
15
3
3
SCK/IO4 3 4 4
GND
15
5
5
SI/RxD 2 6 6
Not used
*1

7
7
TxD2/HS 7 8 8
Not used

9
9
RESET 4 10 10
Not used
*1

11

SO/TxD1/IO3 1 12 
Not used
*1

13

IO1 10 14 
GND
15
15

CLK/IO5 14 16 
GND
15
17

FLMD0/IO0 12 18 
GND
15
19

IO2 13 20 
Note: Reserved pin. Leave this pin open.
