10.5 GND Connector
The banana-jack GND connector is laid out on the target connector side of the FP6.
Note: Part number of the GND connector (banana jack): PB4 (manufactured by HIRSCHMANN)
Figure 10.13 GND Connector (Target Connector Side of the FP6)
GND connector
