PG-FP6 V1.06 1. Overview
R20UT4469EJ0800 Rev.8.00 Page 22 of 188
Oct.01.21
1.6 List of Specifications
Table 1.2 List of Specifications
Category
Items
Specifications
Hardware
specifications
Operating power
supply
• Supplied via the power adapter (5 V, 2 A): recommended
• USB-bus power supply (VBUS 4.5 V min./500 mA max.)
Operating
environment
condition
Temperature: 5°C to 35°C (no condensation)
Storage environment
condition
Temperature: −15°C to 55°C (no condensation)
Package size
(H × W × D)
140 × 95 × 30 mm (not including projections)
Weight
Approximately 245 g
Host PC interface Target host PC: Refer to section 1.5, Operating Environments.
USB connector: USB 2.0 (mini-B type)
Serial port: 9-pin D-Sub male port for RS-232C
*1
Target interface
15-pin D-Sub female target connector
Power supply: 1.8 V to 5.5 V, 500 mA max.
*2
Remote interface 15-pin D-Sub female remote connector
Interface level: 3.3 V
FP6 functions
Operation of the FP6
main unit
• Use of the GUI (FP6 Terminal)
• Use of the gang programming GUI (FP6 Gang Programmer)
• Use of communications commands
• Standalone operation with the use of the buttons of the FP6 main unit
• Remote interface operation using signals from an external control unit
Selectable
programming
environment
Up to eight target environments are selectable for the programming area (384
MB max.)
Security functions of
the FP6 main unit
• Pattern authentication when the main unit is started
• Password authentication when the settings of the security function are
changed
• A limit on the number of times authentication can be attempted
• Reading of RPE files
• Restricting the operation of the FP6 main unit (in terms of the number of
times the target device can be programmed and restriction of the execution
of commands)
• Encrypting the data stored in the FP6 main unit
Attached
items
Power adapter Power adapter for each region
*3
USB cable
Approximately 2 m
Target cable 14-pin type
Cable length: Approximately 42 cm
GND cable
Approximately 1 m
Notes: 1. Connecting to the host PC has to use a cross cable.
2. The maximum power-supply current is 100 mA when USB bus power is being supplied; however, this
depends on the performance of the USB host in terms of the supply of power.
3. The power adapter that comes with the FP6 varies with the region where it is to be used. For the product
type names, see Table 1.1, Product Type Names for Ordering.
