PG-FP6 V1.06 1. Overview
R20UT4469EJ0800 Rev.8.00 Page 20 of 188
Oct.01.21
1.3 FP6 System Configuration
The system configuration of the FP6 is shown below.
Note: The product type name and the standard with which the power adapter that comes with the FP6 complies vary
with the region where it is to be used. Be sure to use the power adapter that is appropriate for your region.
Figure 1.1 Image of FP6 Connection
Table 1.1 Product Type Names for Ordering
Target Region Product Type Name Plug Shape Voltage
Range
*1
Japan
RTE0T00001FWRJP000R AC:
100-240 V
A
Europe and USA
RTE0T00001FWREA000R
SE C BF A
China, Hong Kong,
Chinese Taipei,
South Korea,
Singapore
RTE0T00001FWRAS000R
SE C BF A
Note: This voltage range is for the power adapter. For the voltage intended for the power cable, check the indication
around the plug.
Cautions:
1. Since regulations that apply to the FP6 vary with the region, we cannot ship a product to a region
other than that from which the order was made. For example, if you place an order in Japan, you
cannot purchase a product intended for Europe and the USA.
Please purchase the product from a Renesas Electronics Corporation representative (responsible
for sales) or distributor in the region where it is to be used.
2. If you wish to know which model is available in a region not included in the above table, please
contact either a Renesas Electronics Corporation representative (responsible for sales) or
distributor.
3. The power adapter that comes with the FP6 complies with the regulations that are applicable in the
target region. Its plug is also in the shape that is usable in that region.
