PG-FP6 V1.06 10. Connectors and Cables
R20UT4469EJ0800 Rev.8.00 Page 134 of 188
Oct.01.21
Table 10.3 Pin Configuration of the Target Connector (14-Pin Type)
Signal Name
(PG-FP6)
15-Pin D-Sub Male Connector 14-Pin 2.54-mm Pitch
Multipurpose Female Connector
SCK/IO4
3
1
GND 15 2
CLK/IO5
14
3
FLMD0/IO0 12 4
SI/RxD
2
5
IO1 10 6
SO/TxD1/IO3
1
7
VCC 8 8
FLMD1
6
9
IO2 13 10
TxD2/HS
7
11
GND 15 12
RESET
4
13
Not used *  14
Note: Reserved pin. Leave this pin open.
Left open in the target cable. If you use the same 14-pin connector for debugging, please also refer to the user’s
manual of the emulator.
10.4.2 14-pin to 16-pin conversion adapter for the E1 emulator
When the 16-pin connector is used on the target system, use the 14-pin to 16-pin conversion adapter for the
E1 emulator.
Caution: This conversion adapter is only usable with 78K and V850 target devices.
Remark: For the product information, refer to section 1.4, Optional Products.
