PG-FP6 V1.06 1. Overview
R20UT4469EJ0800 Rev.8.00 Page 21 of 188
Oct.01.21
1.4 Optional Products
We provide useful optional products (separately sold) for use with the FP6.
• 14-pin to 16-pin conversion adapter for the E1 emulator (type name: QB-F14T16-01)
• 20-pin conversion adapter for the PG-FP6 (type name: RTE0T00001FWRB0000R)
• User system interface cable (20-pin to 20-pin) for the E2 emulator (type name: RTE0T00020KCAC0000J)
• User system interface cable (20-pin to 10-pin) for the E2 emulator (type name: RTE0T00020KCAC1000J)
For details on the optional products, refer to the following Web page in the Development Tools section of the
Renesas site.
https://www.renesas.com/pg-fp6
The optional products are also available for purchase from Naito Densei Machida Mfg. Co., Ltd. Contact the
company through the following site for details.
• Web site for Naito Densei Machida Mfg Co., Ltd:
https://www.ndk-m.co.jp
1.5 Operating Environments
1.5.1 Hardware environment
• Host PC
 Processor: At least 1 GHz
 Main memory: We recommend at least 2 GB.
At least 1 GB (or at least 2 GB for 64-bit editions of Windows OS) is required.
 Display: Resolution should be at least 1024 x 768.
 Interface: USB2.0 or serial interface (RS-232C)
1.5.2 Software environment
• Operating System
 Windows 7 (32-bit edition, 64-bit edition)
 Windows 8.1 (32-bit edition, 64-bit edition)
 Windows 10 (32-bit edition, 64-bit edition)
