PG-FP6 V1.06 5. Usage in Standalone Mode
R20UT4469EJ0800 Rev.8.00 Page 76 of 188
Oct.01.21
5.2.2 [Project] menu
The [Project] menu is used to check information about switching the active programming area and checking
the setting file name, program file name, and CRC value.
Table 5.4 [Project] Menu
Main Menu
Submenu
Description
[Project >]
[Project Name
>]
Display the name of the setting file stored in the active programming
area on the message display.*
[PRM Name >] Display the name of the parameter file stored in the active programming
area on the message display.*
[Program File
>]
Display the name of the program file stored in the active programming
area on the message display.*
[File Checksum >] Display the CRC-32 (the sum of the CRC-32 results for all areas which is
displayed during downloading) of the entire file in the message display.*
[Progarea
>]
Pressing the [ENTER] button causes a transition to the next
programming area.
Note: If the file to be displayed has not been downloaded, [n.a.] is displayed. If the file name exceeds 16 characters,
“~” is displayed as the 16th character.
5.2.3 [Utility] menu
The [Utility] menu is used to adjust the LCD contrast and check the firmware version of the FP6 main unit.
Table 5.5 [Utility] Menu
Main Menu
Submenu
Description
[Utility >]
[Set LCD Contr.
>]
Adjust the contrast in the message display. After pressing the [ENTER]
button, the contrast can be adjusted using the [NEXT] (darken) or
[CANCEL] (lighten) button. To fix the contrast, click on the [ENTER]
button.
[F/W Version ] Pressing the [ENTER] button displays the FP6 firmware version.
[RS232C Baud rate
]
Pressing the [ENTER] button displays the current baud rate value set for
the RS-232C host interface.
