PG-FP6 V1.06 2. FP6 Main Unit: Names and Functions of Parts
R20UT4469EJ0800 Rev.8.00 Page 27 of 188
Oct.01.21
2.2 FP6 Connectors
The power-supply connector, serial port, and USB connector are placed on the host interface side of the
FP6.
The target connector, GND connector, and remote connector are placed on the target connector side of the
FP6.
Figure 2.2 FP6 Top View <Connectors>
Figure 2.3 FP6 Host Interface Side
Figure 2.4 FP6 Target Connector Side
USB connector
Target connector
GND connector
Serial port
Power-supply connector
Remote connector
Serial port
USB connector
Target connector GND connector Remote connector
Power-supply connector
