Renesas PG-FP6 V1.06

PG-FP6 V1.06 Appendix D. Electrical Specifications of the Remote Interface
R20UT4469EJ0800 Rev.8.00 Page 180 of 188
Oct.01.21
D.3.2 Bank mode
(1)
Pin name Symbol Parameter or Conditions MIN. TYP. MAX. Unit
CONN
BUSY
PASS
ERROR
t
PLH
Rise time (I
O
=8mA)


5
ns
t
PHL
Fall time (I
O
=8mA)   5 ns
BANK0
BANK1
BANK2
VRF
START
CLEAR
t
PLIN
Low-level width of input signal
50


ms
t
PCNIN
Time from the rise of the CONN signal
until the input signal is acknowledged
1   ms
CONN
tPLIN
tPHL
tPLH
tPCNIN
BANK0
BANK1
BANK2
START
VRF
CLEAR
