7.4.3 conf command
Displays a list of the information stored in the FP6.
Input format
'conf'
Description of the function
Displays information on data downloaded to the FP6 and the settings of the FP6.
Example of usage
Example of Communication Software Terminal Display
>conf
Firmware Version Vx.xx.xx
Board H/W Vx
Serial No.: xxxxxxxxxx
Standard mode unsecured
Active Program Area: 0
Number of Program areas: 8
Max. area size: 384 MByte
Free space: 363 MByte
Area 0: 2 MByte
Area 1: 6 MByte
Area 2: 3 MByte
Area 3: 10 MByte
Area 4: 0 MByte
Area 5: 0 MByte
Area 6: 0 MByte
Area 7: 0 MByte
Area Filename Date Time Range CRC
*0 test-0.hex 2019-10-17 17:35 00000000-00003FFF 2673FC33
1 {unknown data}
2 test-2.hex 2019-10-17 17:35 00000000-00003FFF 2673FC33
3 test-3.hex 2019-10-17 17:35 00000000-00003FFF 2673FC33
4 {unknown data}
5 {unknown data}
6 {unknown data}
7 {unknown data}
Area File name CRC Type
*0 R5F104AA 25BDA75F PR5
test-0.es6 B6D40286 ESF
1 R5F564M 1CC12600 PR5
test-1.es6 0FDBCF7A ESF
2 R7FA6M3AF DEC16EA8 PR5
test-2.es6 ABB4801E ESF
