Renesas PG-FP6 V1.06

PG-FP6 V1.06 Appendix D. Electrical Specifications of the Remote Interface
R20UT4469EJ0800 Rev.8.00 Page 178 of 188
Oct.01.21
D.3 AC Characteristics (T
A
=0 to 40°C, C=0pF (Unloaded Condition))
D.3.1 Standard mode
(1)
Pin name Symbol Parameter or Conditions MIN. TYP. MAX. Unit
CONN
BUSY
PASS
ERROR
t
PLH
Rise time(I
O
=8mA)


5
ns
t
PHL
Fall time (I
O
=8mA)   5 ns
CANCEL
ENTER
NEXT
VRF
START
CLEAR
t
PLIN
Low-level width of input signal
50


ms
t
PCNIN
Time from the rise of the CONN signal until
the input signal is acknowledged
1   ms
CONN
t PLIN
t PHL
t PLH
t PCNIN
CANCEL
ENTER
NEXT
START
VRF
CLEAR
