Renesas PG-FP6 V1.06

PG-FP6 V1.06 Appendix D. Electrical Specifications of the Remote Interface
R20UT4469EJ0800 Rev.8.00 Page 183 of 188
Oct.01.21
(2)
Pin name Symbol Parameter or Conditions MIN. TYP. MAX. Unit
t
PBAIN
Time from the fall of the NEXT signal
until the VRF or START signal can be input
1


ms
t
PINBU
Time from the fall of the VRF, START or
ENTER signal until the rise of the BUSY
signal (When the input signal is input after
having changed the program area)


8000
ms
Time from the fall of the VRF, START or
ENTER signal until the rise of the BUSY
signal (When the input signal is input without
changing the program area)
  50 ms
t
PBUIN
Time from the fall of the BUSY signal
until the CLEAR signal can be input
1   ms
t
PCLPE
Time from the fall of the CLEAR signal
until the fall of the PASS or ERROR signal


50
ms
t
PPENE
Time from the fall of the BUSY signal until the
NEXT signal can be input
1   ms
