PG-FP6 V1.06 7. Usage of Communications Commands
R20UT4469EJ0800 Rev.8.00 Page 92 of 188
Oct.01.21
Example of usage
Command
Status
Status LED
Message Display
Screen Output
lod
Display after execution of the
command (before downloading)
BUSY
*** BUSY ***
Preparing storage ....PASS
Now loading...
Display during downloading BUSY *** BUSY *** ...
Display after normal ending of
the download
PASS
Returns to the display
before executing the
command.
PASS
Display after error ending of the
download
ERROR Returns to the display
before executing the
command.
ERROR: <text>
Example of Communication Software Terminal Display
>lod
[When the MCU supports only the code flash area]
Address range: 0x00000000 to 0x00003FFF, CRC32: 0xC80EBAB6
PASS
>lod fname="sample.hex" ftime="2006-02-24 21:13"
[When the MCU also supports areas other than code flash]
Address range code: 0xFFF00000 to 0xFFFFFFFF, CRC32: 0xD253DA27
Address range data: 0x00100000 to 0x00107FFF, CRC32: 0x0CA407F9
Address range boot: 0xFF7FC000 to 0xFF7FFFFF, CRC32: 0xE39BE9B8
PASS
