ADF
Original orientation Control Panel Key
top edge placed first
top edge touches rear of ADF
• Originals are normally rectangular ( ) or horizontally long ( ). However, the table above uses
squares to make original orientation easier to understand. Even if the actual shape of the original
is different, the combination of original orientation and the orientation specified on the scanner
driver does not change.
• When you specify full color, gray scale, or [Auto Colour Select] for Scan Type, and single page
TIFF/JPEG or multi-page TIFF is selected as the file type, refer to the table below for how to place
originals. Originals placed in orientations that are not recommended in the table might appear
incorrectly top/bottom oriented on client computer displays.
How to set an original
Place Original orientation
Placing an Original on the Exposure Glass
Placing an Original in the ADF
Original Settings
This section explains the settings for the scanning the sides of originals.
One-sided original
This section explains the settings for scanning only one side of originals.
1. Press [Original Feed Type].
