Ricoh Aficio MP C5000 Function Guide

• wlan can be specified only when the IEEE 802.11 interface is installed.
Interface name Interface configured
Ether Ethernet interface
Wlan IEEE 802.11 interface
Address configuration
Use the following command to configure a WINS server IP address:
wins “interface_name” {primary|secondary} “IP address”
• Use the “primary” command to configure a primary WINS server IP address.
• Use the “secondary” command to configure a secondary WINS server IP address.
• Do not use “255.255.255.255” as the IP address.
NBT (NetBIOS over TCP/IP) Scope ID Selection
You can specify the NBT scope ID.
msh> wins “interface_name” scope “scope ID”
• The scope ID can be entered using up to 31 alphanumeric characters.
• Be sure to specify the interface.
• wlan can be specified only when the IEEE 802.11 interface is installed.
Interface name Interface configured
Ether Ethernet interface
Wlan IEEE 802.11 interface
wsmfp
Use the “wsmfp” command to view and configure WSD (Device), WSD (Printer) and WSD (Scanner)
settings.
Viw settings
msh> wsmfp
Comment settings
msh> wsmfp comments “comment”
• If you do not specify a comment, current setting is displayed.
Location configuration
mah> wsmfp location “location”
4. Monitoring and Configuring the Printer
200
4

Ricoh Aficio MP C5000 Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Resolution	200 x 200 dpi
Duplex Printing	Yes
Max Document Enlargement	400%
Max Document Reduction	25%
Print Speed	50 ppm
Resolution	1200 x 1200 dpi
Copy Speed	50 cpm
Paper Capacity	Maximum: 4, 400 sheets
Scanner Type	Flatbed, ADF
Connectivity	USB, Ethernet
Operating System Compatibility	Windows, Mac
