Installation: Fax Option Type 9001 (D418-00)
SM 1 D418
Fax Option
Type 9001
D418
1. INSTALLATION
1.1 INSTALLATION: FAX OPTION TYPE 9001
(D418-00)
1.1.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1. FCU 1
2. Interface Board 1
3. Fax Keytop 2
4. Ferrite Core (ZCAT1730-730A) 1 (NA/TWN)
4’ Ferrite Core (TFC-25-15-12A) 1 (EU/AA/CHN)
5. Ferrite Core (RFC-9) 1
6. Screws (Blue M3 x 6) 7
7. Speaker Unit 1
8. Super G3 Decal 1
9. Clamp 2
10. Telephone Cable (NA only) 1
11. FCC Decal (NA Only) 1
12. Serial Number Decal 1
13.
Multi-Language Decals 1 (Excluding NA)
/ 2 (EU)
14. EMC Address Decal 1 (EU only)
15. Quick Reference Guide 1 (Excluding EU)
