Installation: Fax Option Type 9001 (D418-00)
SM 3 D418
Fax Option
Type 9001
D418
4. Attach the interface board [A] to the controller board securely (
x 2).
5. Remove the jumper [A] on the MBU [B] and set it to the ON position.
 If the jumper remains at the OFF position, this will cause SC672 (Controller
Startup Error) to appear.
