Replacement and
Adjustment
D454 40
SM
1.6
ELECTRICAL COMPONENTS: MAIN 1
1.6.1
TOP TRAY FULL SENSOR (E)
1.
T
op tray (
p.5)
2.
Paper exit cover [A] (
x 1)
3.
T
op tray full sensor (E) bracket (
x 1)
4.
T
op tray full sensor (E) [A] (
x 1,
x 1)
