Electrical Components: Main 1
SM 41 D454
Multi-Folding
Unit FD5000
D454
1.6.2 TOP TRAY FULL SENSOR (R)
1. Top tray ( p.5)
2. Top tray full sensor (R) [A] ( x 1, x 1)
1.6.3 VERTICAL PATH PAPER SENSOR
1. Top tray ( p.5)
2. Remove the bracket ( x 5)
3. Vertical path paper sensor [A] ( x 1, hooks)
