D454 120 SM
2.5.6 MOTORS, SOLENOIDS AROUND THE TOP TRAY
1. Horizontal Transport Motor
2. Top Tray Exit Motor
3. Reverse JG Solenoid
4. Exit JG Solenoid
5. Top Tray Transport Motor
6. Entrance JG Solenoid
7. Top Tray JG Solenoid
