Electrical Components
SM 121 D454
Multi-Folding
Unit FD5000
D454
2.5.7 MOTORS, SENSORS TOP
1. Dynamic Roller Lift Motor
2. Dynamic Roller Transport Motor
3. Dynamic Roller HP Sensor
4. Fold Plate Motor
5. Registration Sensor
