Service Call Conditions
SM Appendix 3-47 D062/D063/D065/D066
Appendix:
Service Call
Conditions
Z-fold stopper 1 Motor error
779 B
The bottom fence HP sensor
detected that:
The bottom fence did not
arrive at the home position at
the specified time.
-or-
The bottom fence failed to
leave the home position at
the specified time.
Motor overcurrent
Motor driver overheat
Motor harness loose
Z-Fold feed motor error
780 B
The feed motor does not attain
the prescribed speed within
the specified time.
Feed motor disconnected,
defective
Feed motor overloaded due to
obstruction
Feed motor lock
Z-Fold lower stopper motor
781 B
The lower stopper motor does
not attain the prescribed speed
within the specified time.
Lower stopper motor disconnected,
defective
Lower stopper motor overloaded
due to obstruction
Lower stopper HP sensor
disconnected, defective
Z-Fold upper stopper motor
782 B
The upper stopper was not
detected at the home position
after the motor remained on long
enough to move it 128.7 mm.
Upper stopper motor disconnected,
defective
Upper stopper motor overloaded
due to obstruction
Upper stopper HP sensor
To Next Page
