Service Call Conditions
D062/D063/D065/D066 3-46 SM Appendix
Horizontal Transport Motor Error Multi Folder (D454)
The motor drive PCB detected an error at the motor.
778-1 D
Motor harness or connector loose, broken, defective
Motor or motor drive board defective
Top Tray Exit Motor Multi Folder (D454)
The motor drive PCB detected an error at the motor.
778-2 D
Motor harness or connector loose, broken, defective
Motor or motor drive board defective
Top Tray JG Motor Multi Folder (D454)
The top tray JG HP sensor did not detect the top tray junction gate at (or
out of) its home position. The 1st occurrence causes a jam, and the 2nd
occurrence causes this SC code.
778-3 D
Top tray JG HP sensor dirty
Sensor harness or connector loose, broken, defective
Top tray JG motor harness or connector loose, broken, defective
Sensor defective
Motor or motor drive board defective
Entrance JG Motor Multi Folder (D454)
The entrance junction gate HP sensor did not detect the entrance
junction gate at (or out of) its home position. The 1st occurrence causes
a jam, and the 2nd occurrence causes this SC code.
778-4 D
Entrance JG HP sensor dirty
Sensor harness or connector loose, broken, defective
Entrance JG motor harness or connector loose, broken, defective
Sensor defective
Motor or motor drive board defective
