Service Call Conditions
SM Appendix 3-45 D062/D063/D065/D066
Appendix:
Service Call
Conditions
Jogger Top Fence Motor: 3K Finisher B830
775 B
The top fence HP sensor detected that:
The top fence did not arrive at the home position within the specified number
of pulses.
-or-
The top fence failed to leave the home position within the specified number
of pulses.
If the jogger top fence motor is operating:
1. Top fence HP sensor harness loose, broken, defective
2. Top fence HP sensor defective
If the jogger top fence motor is not operating:
1. Motor blocked by an obstruction
2. Motor harness loose, broken, defective
3. Motor defective
4. Finisher main board defective
Jogger Bottom Fence Motor (B830)
776 B
The bottom fence HP sensor detected that:
The bottom fence did not arrive at the home position at the specified time.
-or-
The bottom fence failed to leave the home position at the specified time.
If the jogger bottom fence motor is operating:
1. Bottom fence HP sensor harness loose, broken, defective
2. Bottom fence HP sensor defective
If the jogger bottom fence motor is not operating:
1. Motor blocked by an obstruction
2. Motor harness loose, broken, defective
3. Motor defective
4. Finisher main board defective
