Service Program Mode Tables
D062/D063/D065/D066 4-58 SM Appendix
b11: GAIN_ERR1_BK_L_BO
b10: GAIN_ERR1_BK_ L _BE
b 9: GAIN_ERR1_FC_ L _BO
b 8: GAIN_ERR1_FC_ L _BE
b 7: GAIN_ERR1_BK_ L _GO
b 6: GAIN_ERR1_BK_ L _GE
003 Gain2:First
Displays the eroor flag for the gain 1 first data.
0: No error, 1: Error
b11: GAIN_ERR2_BK_F_BO
b10: GAIN_ERR2_BK_F_BE
b 9: GAIN_ERR2_FC_F_BO
b 8: GAIN_ERR2_FC_F_BE
b 7: GAIN_ERR2_BK_F_GO
b 6: GAIN_ERR2_BK_F_GE
004 Gain2:Last
Displays the eroor flag for the gain 1 last data.
0: No error, 1: Error
b11: GAIN_ERR2_BK_L_BO
b10: GAIN_ERR2_BK_ L _BE
b 9: GAIN_ERR2_FC_ L _BO
b 8: GAIN_ERR2_FC_ L _BE
b 7: GAIN_ERR2_BK_ L _GO
b 6: GAIN_ERR2_BK_ L _GE
005 Black Level :First :FC
Displays the eroor flag for the first full color data at the black level adjustment.
0: No error, 1: Error
b11: BLACK_ERR_FC_F_BOO
b10: BLACK_ERR_FC_F_BEO
b 9: BLACK_ERR_FC_F_BOE
b 8: BLACK_ERR_FC_F_BEE
b 7: BLACK_ERR_FC_F_GOO
