Ricoh D065 - Page 592

Service Program Mode Tables
SM Appendix 4-59 D062/D063/D065/D066
Appendix:
Service
Program
Mode Tables
b 6: BLACK_ERR_FC_F_GEO
006 Black Level :Last :FC
Displays the eroor flag for the last full color data at the black level adjustment.
0: No error, 1: Error
b11: BLACK_ERR_FC_L_BOO
b10: BLACK_ERR_FC_ L _BEO
b 9: BLACK_ERR_FC_ L _BOE
b 8: BLACK_ERR_FC_ L _BEE
b 7: BLACK_ERR_FC_ L _GOO
b 6: BLACK_ERR_FC_ L _GEO
007 Black Level :First :BK
Displays the eroor flag for first B/W data at the black level adjustment.
0: No error, 1: Error
b11: BLACK_ERR_BK_F_BOO
b10: BLACK_ERR_BK_F_BEO
b 9: BLACK_ERR_BK_F_BOE
b 8: BLACK_ERR_BK_F_BEE
b 7: BLACK_ERR_BK_F_GOO
b 6: BLACK_ERR_BK_F_GEO
008 Black Level :Last :BK
Displays the eroor flag for last B/W data at the black level adjustment.
0: No error, 1: Error
b11: BLACK_ERR_BK_L_BOO
b10: BLACK_ERR_BK_ L _BEO
b 9: BLACK_ERR_BK_ L _BOE
b 8: BLACK_ERR_BK_ L _BEE
b 7: BLACK_ERR_BK_ L _GOO
b 6: BLACK_ERR_BK_L_GEO
4647 [Read Hard Error]
001 Power-ON
