Service Program Mode Tables
D062/D063/D065/D066 4-68 SM Appendix
4750 Main Scan White Level: AVG B
Leading Edge
001
Displays the average level of the main scan white for the leading edge of Blue
signal.
[0 to 255 / - / 1 digit]
Trailing Edge
002
Displays the average level of the main scan white for the trailing edge of Blue
signal.
[0 to 255 / - / 1 digit]
4784* White Level Peak Range R
Min: FC
001
Adjusts the lower limit threshold for the white level peak range of Red signal in
the full color mode.
[0 to 255 / 64 / 1 digit]
Max: FC
002
Adjusts the upper limit threshold for the white level peak range of Red signal in
the full color mode.
[0 to 255 / 245 / 1 digit]
Min: BK
003
Adjusts the lower limit threshold for the white level peak range of Red signal in
the B/W mode.
[0 to 255 / 64 / 1 digit]
Max: BK
004
Adjusts the upper limit threshold for the white level peak range of Red signal in
the B/W mode.
[0 to 255 / 245 / 1 digit]
