3000-Sheet Finisher (D460)
D062/D063/D065/D066 2-46 SM
7. Attach the cushion [A] to the right side of the upper cover.
If you are installing the cover interposer tray, do not attach the cushion here.
Attach it to the cover interposer tray. The cover interposer tray must be
installed before you dock the finisher and tray with the main machine.
8. Install the entrance guide plate [B] ( x 2) (M3 x 6).
