Ricoh D065 - Page 93

3000-Sheet Finisher (D460)
SM 2-45 D062/D063/D065/D066
Installation
5. Install the grounding plate [A] (
x 2) (M3 x 6).
 Set the grounding plate so that there is no gap between the grounding plate
and the bottom frame of the finisher (as shown).
6. Install the table extension [A] as shown (
x 2) (M4 x 8).
 The edge of the table extension should be aligned with the edge of the finisher
(as shown).
