B245/B276/B277/B268/B269 Service Manual 18-Jan-06
151
printing margin for image adjustments.
4012 1 Leading edge
4012 2 Trailing edge
4012 3 Left
4012 4 Right
[0 ~ 9.0 / 1.0 / 0.1 mm/step]
4013
Scanner Free Run
4013 1
Performs a scanner free run with the exposure lamp on. Press ON or to start.
Press OFF to stop.
4015*
White Plate Scanning
Start position
[–3.0 ~ +6.0 / 0.0 / 0.1 mm/step]
4015 1
Adjusts the scanning start position on the white plate for auto shading. The base
value stored in the machine is 15.2 mm toward the white plate from the scanner
HP. This SP setting specifies the offset from this base value.
Scanning length
[–3.0 ~ +6.0 / 0.0 / 0.1 mm/step]
4015 2
Adjusts the length of the white plate scan, in the main scan direction. The scan
begins at the start position set above [in SP 4015 1] and extends for the
specified length. The base value stored in the machine is 4.76 mm. This SP
setting specifies the offset from this base value.
4301
Display-APS Data
4301 1
Displays the status of the APS sensors and platen/DF cover sensor (
p.191).
4303*
APS Small Size Original
[0 = No (not detected) / 1 = Yes (A5/HLT LEF)]
4303 1
Selects whether or not the copier will consider the original to be A5/HLT LEF
when the APS sensors cannot detect its size. If “Yes” is selected, paper sizes
that cannot be detected by the APS sensors are regarded as A5/HLT LEF. If
“No" is selected, “Cannot detect original size” will be displayed.
4305*
APS Priority
[0 = Normal / 1 = A4/LT / 2 = 8K/16K]
4305 1
1. A4/LT
North America model: When the ASP detects the LT size, the controller
interprets it as the A4 size.
