Quick keys Parameter Default Range
Standard
Sets the panel programming options in compliance with the selected
standard.
EN 50131 (G2)
For EN 50131 (G2), see page 92.
PD6662:2010
(BS 8243:2010)
By selecting this standard:
• Configurable parameters applicable for this standard can be set as
needed (see page 94).
• Parameters for the HU (Hold-Up) Alarm Confirmation are
automatically set, and any respective outputs are activated
accordingly (see HU Confirmation Al. on page 142).
NOTE: See below for HU Alarm Confirmation description and the
required action for non-reinstated HU devices.
HU Alarm Confirmation Description:
Part of the BS 8243:2010 standard, "HU alarm confirmation" automatically
sends a "confirmed" alarm notification to the monitoring station when at
least 2 separate, sequential HU (panic) alarms occur during the "HU
confirmation time period" – which is fixed at 8 hours.
The alarms must be triggered from different HU devices – for example, 2
panic alarms that are each triggered from a different keypad, or that are
triggered from 1 keypad and 1 keyfob (the keyfob must be installer-
configured to be used for panic alarms)
At the expiration of the HU confirmation time period if only one HU
(panic) alarm has occurred – but not the second one that is required for
confirmation, then the system is automatically reinstated (restored to a
normal state).
At the end of the HU confirmation time period, all non-reinstated HU
devices are automatically bypassed – which will appear in the system's
event log, the monitoring station will be notified, and there will be an
indication at the panel to notify the user.
IMPORTANT: As these non-reinstated (now bypassed) devices are still
in an alarm state, perform a system restore per the system's definition.
