Zones  Parameters  By Category  Label
Quick keys Parameter Default Range
 
Label
The label identifies the zone in the system. Up to 16 characters. Type a
descriptive label over the default “ZONE”
Zones  Parameters  By Category  Zone Partition (and Group)
Quick keys Parameter Default Range
  ZZZ
Zone Partition
1. Use scroll keys and enter a zone number (ZZZ), then press OK. If a zone
displays with “(--:-- -- --: -- --)” it means that zone has not yet been
allocated.
2. After you have selected an allocated zone, enter the number of the
partition and then press OK. If you had defined more than 8 (default)
partitions to be available in the system (see the parameters for Partition
Qty, page 101), You will need to scroll to get to the partition that you
want the zone to be in. As there are 32 partitions maximum, the
available partitions are in blocks of partitions. When you scroll to the
appropriate block, enter the partition number; it will display as P=##
(whereas ## is the partition).
3. Press OK.
  ZZZ
ABCD
Group
A group is a specific area (zone) that can be armed within a specific
partition. There are up to 4 groups possible per partition (groups A—D).
1. Select zone partition (see procedure directly above)
2. For each applicable group letter (A—D), toggle to select it (Y), or to
clear it.
3. Press OK.
