11
2017 Page 164 5IN2413 B
Quick Keys Parameter
–
Voice
Reports to the monitoring station will be done through the GSM
network. Reporting by Voice can be established through different
channels. The optional channels depend on the hardware installed in
your system. Select the required channel:
1. PSTN/GSM:
2. GSM/PSTN:
3. PSTN Only:
4. GSM Only: The outgoing calls are executed through the GSM
audio channel only.
Enter the monitoring station telephone number including area code
and special characters (if required):
Function Results
Stop dialing and wait for a new dial tone W
Wait a fixed period before continuing ,
Send the DTMF * character *
Send the DTMF # character #
Delete numbers from the cursor position
[*]
simultaneously
–
IP
Encrypted events are sent to the monitoring station over the IP or
GPRS network using TCP/IP protocol. 128 BIT AES encryption is
used. RISCO Group’s IP/GSM Receiver Software located at the MS
site receives the messages and translates them to standard protocols
used by monitoring station applications (For example; contact ID).
Note
To enable GPRS communication the SIM card has to support GPRS
channel.
Reporting by IP can be established through different channels. The
optional channels depend on the hardware installed in your
system. Select the required channel via the Configuration Software
as follows:
1. IP/GPRS: The panel checks for the availability of the IP
network. During regular operation mode all calls and data
transmission are carried out using the IP network line. In the
case of trouble in the IP network, the report is routed to the
GPRS network.
