2017 Page 205 5IN2413 B
Quick Keys Parameter Default Range
Blink
40
Defines the number of times that the strobe will blink in a minute.
20 [Times/Min]
30 [Times/Min]
40 [Times/Min]
50 [Times/Min]
60 [Times/Min]
Arm Squawk
01
01—20 (seconds)
The time that the strobe will blink when the system is armed.
Note
If the siren’s squawk strobe is defined as NO (see Sounder, page 195),
then this parameter will be ignored.
Volume
Sets the WL siren's internal speaker Alarm volume - range is between 0
(silent) to 9 (maximum). After setting, sound will be emitted by the
internal speaker to enable evaluation of the selected volume level.
Alarm
9 (1—9)
General alarm volume
Squawk
9 (1—9)
Squawk sound alarm
Exit Entry
9 (1—9)
Notification of system status in exit or entry delay.
Serial No.
The identifying 11-digit number of the sounder (display only)
Supervision
Determines if this zone will be supervised by the system expander
according to the time defined under the timer RX Supervise, page 79).
Lamp Times
Specify here the sounder lamp illumination duration.
Lamp Start - Specify here the start time for the sounder lamp to be
activated.
Lamp Stop - Specify here the stop time for the sounder lamp to be
deactivated.
