Riso MZ970 - Page 247

Replacing Consumables
Replacing the Master Roll
244
5
Open the Master Roll Holder.
6
Remove the depleted Master core.
Note:
• Dispose the depleted master core according to
the disposal rule of your local community.
)p.253
7
Install a new Master Roll.
Remove the plastic shrink wrap from the new
Master Roll, and place in with the mark to the
left.
Important!:
• Take care not to damage the section when
removing the shrink wrap.
If the section is bent or the perforation cut,
the master will become unusable.
• Do not remove the tape yet.
8
Close the Master Roll Holder.
Remove the tape once the Master Roll Holder has
been closed.
9
Insert the leading edge of the master
under the Master Guide Flap.
Insert the leading edge of the master into its
entrance under the Master Guide Flap and
advance it as far in as it will go ( ). If the Master
is loose, turn the flange at the right towards the
rear and rewind ( ).
Master Roll Holder
Do not remove
the tape
Master Guide Flap
Flange
