Reference Modification no.
- 0 -
Page
156
Date
1997 02 01
Main
914 F
01478
Renewal of the bearing bush { is not planned as after pressing in the bush,
the internal bore and the lubricating bore P are machined. At wear of the
bearing bush { the complete ignition cover with pressed-in and machined
bush has to be replaced or to be sent for repair to an authorized overhaul
facility.
Check oil seal q 32x52x7 for crankshaft, replace if necessary. Press in new
oil seal with insertion jig, part no. 877 270. Check whether at the leakage
bore w emergency of oil or water is visible.
Check rotary seal e for water pump seal-
ing. At emergency of liquid, renew rotary
seal and oil seal r. Visually check support
t for electric starter.
y = Drive shaft for mechanical rev. counter.
11
13
18
10
Pic. 114
14
e
16
17
00383
