7K • Chapter 21
21-30
Select Individual RBI-1 User Function Outputs
Control one or more RBI-1 User Function Outputs.
• Each output in a list of outputs may be latched ON or OFF.
• List the outputs to be controlled by entering any combination of digits 1
through 8.
Command Form:
Command Form
Select User Function Outputs Latched OFF (RBPW) 12 (list the outputs) *
Select User Function Outputs Latched ON (RBPW) 11 (list the outputs) *
Acknowledgment: Sends OK
Errors:
Error Meaning
OFF remote base is disabled
? err 1 wrong number of digits entered
? err 2 illegal digit entered
Default Condition: After a 7K cold reset, the outputs are off. After a power
failure, the outputs will be set to the state they were in before the power failure.
Example:
To turn ON user function output 1, enter the following:
(RBPW) 11 1 *
To turn OFF user function output 2, enter the following:
(RBPW) 12 2 *
To turn ON user function outputs 7 and 8, enter the following:
(RBPW) 11 7 8 *
