7K • Appendix A
A-40
Command Quick Reference
Page Command Name Form and Data Digit Default User
9-1
Scheduler
9-2 Create Setpoint (PW) 28 (setpoint, macro, month, day,
hour, minute) *
setpoint = 00-99, 2 digits
macro = 4 digits
month = 01-12 or 99, 2 digits
day = 01-75 or 99, 2 digits
(See Day Code Table page A-46.)
hour = 00-23 or 99, 2 digits
minute = 00-59 or 99, 2 digits
(Note: 99 is the wild card)
no
setpoints
9-6 Delete One Setpoint (PW) 28 (setpoint) *
setpoint = 00-99, 2 digits
none
9-6 Delete Range of Setpoints (PW) 28 (first setpoint) (last setpoint) *
setpoint = 00-99, 2 digits
none
9-7 Enable/Disable Scheduler (PW) 63 15 x *
0 = OFF (disabled)
1 = ON (enabled)
ON
enabled
10-1
CTCSS Functions
10-2 Enable/Disable CTCSS Encoder (PW) 02 x *
0 = disabled 5 = 5 seconds
1 = continuous 6 = 6 seconds
2 = 2 seconds 7 = 7 seconds
3 = 3 seconds 8 = 8 seconds
4 = 4 seconds 9 = 9 seconds
0
disabled
10-3 Select Frequency of CTCSS (PW) 03 xx *
(00-63)
See TS-32 Programming, page 10-5.
all outputs
open
11-1
DTMF Decoder
11-2 Enable/Disable Command Response
Messages
(PW) 63 02 x *
0 = OFF (disabled)
1 = ON (enabled)
ON
enabled
11-3 Select DTMF Priority/Scan (PW) 89 (Rx1, Rx2, Rx3, PH) *
0 = no access to DTMF decoder
1 = Priority 1 (highest priority)
2 = Priority 2
3 = Priority 3
4 = Priority 4
5 = Scan this device
Priorities:
Rx1 = 3
Rx2 = 4
Rx3 = 1
PH = 2
11-5 Select Rx1-to-DTMF Decoder Access
Mode
(PW) 57 06 x *
0 = no access
1 = carrier access
2 = PL access
3 = And-PL access
4 = Or-PL access
5 = Anti-PL access
1
carrier
access
11-5 Select Rx2-to-DTMF Decoder Access
Mode
(PW) 57 07 x *
Same as above
1
carrier
access
