7K • Appendix D
D-2
22K¾ 5% 1/4W 1 R5
27K¾ 5% 1/4W 2 R75, R83
47K¾ 5% 1/4W 2 R6, R59
51K¾ 5% 1/4W 1 R117
68K¾ 5% 1/4W 4 R76, R84, R93, R95
82K¾ 5% 1/4W 2 R74, R82
100K¾ 5% 1/4W 5 R30, R34, R37, R53, R91
200K¾ 5% 1/4W 3 R31, R35, R38
300K¾ 5% 1/4W 1 R7
470K¾ 5% 1/4W 4 R66, R67, R68, R120
4.7K¾ 8-pin sip 5 R1, R8, R9, R11, R20
4.7K¾ 10-pin sip 4 R2, R3, R4, R18
10K¾ 14-pin DIP 2 R10, R19
50K¾ 3/8" pot
12 R97, R98, R99, R100, R101, R102, R103, R104, R105,
R106, R107, R108
Capacitors
3-23pF trimmer 1 C22
18pF ceramic NPO 3 C2, C3, C23
47pF ceramic NPO 3 C67, C71, C74
100pF ceramic 39 C28, C29, C30, C31, C32, C33, C34, C35, C36, C37,
C38, C39, C40, C42, C43, C46, C47, C48, C49, C50,
C51, C52, C53, C65, C69, C72, C98, C103, C111,
C112, C113, C114, C115, C116, C117, C118, C119,
C120, C121
470pF ceramic NPO 2 C96, C101
.001µF film 3 C16, C60, C86, C122
.0022µF film 1 C17
.0039µF film 1 C85
.1µF film 1 C20
.1µF MLC 28 C1, C4, C5, C6, C7, C8, C9, C10, C11, C12, C13, C14,
C15, C19, C21, C25, C26, C27, C41, C44, C45, C54,
C55, C56, C57, C58, C59, C110
.47µF film 16 C18, C66, C70, C73, C75, C76, C77, C78, C79, C81,
C84, C95, C100, C104, C105, C106
1µF tantalum 4 C24, C62, C63, C88
4.7µF tantalum 5 C87, C90, C91, C94, C99
10µF tantalum 13 C64, C68, C80, C82, C83, C89, C92, C93, C97, C102,
C107, C108, C109
330µF electrolytic 1 C61, C123
Diodes
1N4002 2 D12, D13
ICTE-15/MPTE-15 1 D11
SA40A 10 D1, D2, D3, D4, D5, D6, D7, D8, D9, D10
