Parts Lists and Schematics

D-3

Transistors

2N3904 1 Q4

2N7000/VN10KM 9 Q7, Q8, Q9, Q10, Q11, Q12, Q13, Q14, Q15

MPQ3904 3 Q1, Q2, Q3

RFP12N08L 2 Q5, Q6

Integrated Circuits

27C256 factory program 1 U5

74C906 3 U29, U30, U31

74HC00 1 U24

74HC04 1 U26

74HC86 2 U27, U28

74HC138 2 U7, U8

74HC139 2 U6, U11

74HC251 2 U13, U14

74HC259 3 U15, U16, U17

74HC374 3 U18, U19, U20

74HC4078 1 U25

CA3080 1 U32

CD4053 1 U36

DS1210 1 U3

DS1232 1 U1

HD6340 1 U9

HD63B09 1 U2

HM62256LP 1 U4

ICM7170 1 U12

LM317 1 U21

LM7805 1 U22

LMC660 4 U33, U34, U37, U38

MF6CN-50 1 U23

MT8812 1 U35

MT8880 1 U10

Crystals

32.768KHz 1 Y2

3.579MHz 1 Y3

4.000MHz 1 Y1

Batteries

lithium 3V 2 B1, B2

Switches

push-button, momentary 1 S1

DIP switch, 8 pole 1 S2

Ferrite Beads

2943666661 1 L1
