Scanlab RTC 5 PC Interface Board - Page 564

RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
564
innovators for industry
Ctrl Command set_mode
Support status This RTC
®
2 command is not supported by the RTC
®
5.
Replaced by There is no equivalent command for the RTC
®
5, because its image field correction
algorithm is always enabled. Instead, a 1-to-1 correction file can be loaded.
Ctrl Command set_piso_control
Support status This RTC
®
3/RTC
®
4 command is not supported by the RTC
®
5.
RTC
®
4  RTC
®
5 This command is not needed for operation of the RTC
®
5.
For data transfer in accordance with the SL2-100 protocol, the bi-directional
communication between the scan system and the RTC
®
5 does not depend on the data
cable length.
For data transfer in accordance with the XY2-100 protocol, the timing of the
communication must be further on adjusted to reflect the length of the data cable; but the
adjustment is now realized via a jumper at the XY2-100 converter (see page 42).
Ctrl Command set_speed
Support status This RTC
®
2 command is not supported by the RTC
®
5.
Replaced by set_jump_speed (page 438), set_mark_speed (page 448)
Ctrl Command set_wobbel_xy
Support status This RTC
®
4 command is not supported by the RTC
®
5.
Replaced by set_wobbel (page 501), set_wobbel_mode (page 505)
Ctrl Command set_yag_parameter
Support status This RTC
®
2 command is not supported by the RTC
®
5.
Replaced by There is no equivalent command for the RTC
®
5.
Ctrl Command write_da
Support status This RTC
®
2 command is not supported by the RTC
®
5.
Replaced by write_da_1 (page 557)
List Command write_da_list
Support status This RTC
®
2 command is not supported by the RTC
®
5.
Replaced by write_da_1_list (page 557)
