Changes from revision 1.5 to revision 1.6
Page Name of section / command Change
570 chapter 14 "Technical Specifications
of the RTC
®
5 PC Interface Board"
Added: Specifications for “SPI / I2C” connector and
“STEPPER MOTOR” connector
573 chapter 14.1 "Compliance with EC
Guidelines for Electromagnetic
Compatibility (EMC)"
Added.
573 chapter 14.2 "Compliance with FCC
Rules"
Added.
575
and
589
"Software" and chapter 15.3.4
"Installing the Drivers and the RTC
®
5
Software"
Warning added: Standby or sleep modes of the operating
system must be deactivated
591 chapter 16 "Appendix B: The RTC
®
5-
Express Board"
Added.
385 read_analog_in command Added.
Page Name of section / command Change
23 chapter 1.3.1 "Delivered Software"
and further chapters
Added: The RTC
®
5 software package now includes drivers
for 64-bit WINDOWS operating systems as well as Win32-
and Win64-based DLLs, but no longer the MS Visual Studio
runtime libraries. Note the corresponding comments in
"Installing the RTC
®
5 Software", page 58,
"User Applications and Demo Software", page 59,
"Initialization and Program Start-Up", page 62 and
"Data Types", page 226.
26 chapter 2.2.2 "Software" Added: Requirements for new and older RTC
®
5 software
packages (new RTC
®
5 DLLs need at least WINDOWS XP SP2)
47 "I/O Circuits" for LASER connector Added.
92 chapter 6.9.1 "Free Variables" Added.
114 "Mode 3" for Sky Writing Added (as of version DLL 531, OUT 532).
138 chapter 7.4.8 "Pulse Picking Laser
Mode"
Added.
165 chapter 8.3 "Online Positioning" Change (with version DLL 531, OUT 532): If both memory
locations contain identical data types (with identical bit#31
codings) at the time of the request via apply_mcbsp (or
apply_mcbsp_list), then the most recently copied value will
always be used (older DLL/OUT versions always use the value
in memory location 2).
177 chapter 8.7 "Processing-on-the-fly
(Optional)"
Correction via McBSP interface mit zusätzlicher McBSP-
Eingabe (see new sections page 181 and page 183 and
chapter 8.7.5 "Deactivating Processing-on-the-fly
Corrections", page 186)
207 chapter 9.1.7 "McBSP Interface" Added: set_mcbsp_out_ptr
211 New note about "External List Start" External starts are suppressed after pause_list, stop_list or
set_wait.
